HAAGE Distillation Analyzer DA 30.25
The HAAGE distillation analyzer DA 30.25 possesses a microprocessor control. The equipment is pre-programmed with all the necessary distillation parameters for each boiling group. Several individual units can autonomously be operated by either a HAAGE DA 30.25 or an external PC. Details about all relevant distillation processes are saved on the connected DA 30.25 or an external PC.
This distillation analyzer meets the following standards for the distillation of products, solvents, and crude oil:
- ASTM D86 Group 0, 1, 2, 3: Distillation of hydrocarbons up to zu 300°C FBP, all sorts of gasoline, jet fuels, engine oils, and more
- ASTM D86 Group 4: Distillation of diesel fuels, gas oil, fuel oils, heavy oil products, etc., up to 420°C FBP
- ASTM D1078 Group solvents (visual - manual dry point determination)
- ASTM D1078 Group solvents (automatic dry point determination)
- ASTM D1078 Group 7 und 8 (modified dry point determination)
- ASTM D285 (modified), Group 6: Distillation of crude oil
| Output range | |
| Calibration | automatic for temperatures and volumes |
| Dry point | determined automatically for solvents, PT100, 200 ml pistons, accessories |
| Sample volume | 100 ml, 200 ml |
| Accuracy | +/- 0,1 ml volume, +/- 0,01°C temperature |
| Boiling point | 0 – 420°C |
| Technical specifications | |
| Connection voltage | ~ 235 V AC, 50 ~ 60 Hz, ± 10%, 110V optional |
| Operating voltage | 220 V DC |
| Power supply | approx. 3.6 kW |
| Dimensions | width: 515 mm, depth: 500 mm, height: 670 mm |
| Weight | approx. 86.0 kg |
Equipment and accessories
- Distillation piston 125 ml, 200 ml
- Ceran heat plates Ø 32 mm, 38 mm, 50 mm
- Follow-up control with stepping motor
- Cooling with mechanical refrigeration unit
- Resistance thermometers Pt 100, with cable and plug
- Scaled measuring cylinder with disposable stainless steel base
- Condensation pipe wiper
All rights to technical modifications reserved
